What is Modbus?
Quick answer: Modbus is an open, royalty-free request/response protocol for industrial devices, first published by Modicon in 1979. A master (client) reads or writes coils and 16-bit registers on slaves (servers) using function codes. It runs over serial lines as Modbus RTU or ASCII and over Ethernet as Modbus TCP.
Modbus is a serial communication protocol originally published by Modicon (now Schneider Electric) in 1979 for use with programmable logic controllers (PLCs). It has since become a de facto standard in industrial automation and is one of the most widely used protocols for connecting electronic devices in factories, power plants, and building automation systems.
Why Modbus is Still Popular
- Simple & Open - Easy to implement, royalty-free, and well-documented
- Widely Supported - Supported by virtually every industrial device manufacturer
- Reliable - Proven over 45+ years of industrial use
- Interoperable - Devices from different vendors can communicate seamlessly
A Brief History
Modicon publishes the original Modbus specification for serial communication (RTU/ASCII)
Modbus TCP/IP is released, bringing Modbus to Ethernet networks
Modbus Organization takes over protocol management and maintenance
Still the most widely used industrial protocol worldwide, with millions of devices deployed
How does Modbus work?
Modbus uses a Master/Slave (also called Client/Server) architecture. The master device initiates requests, and slave devices respond with the requested data or perform the requested action.
Communication Flow
Key Concepts
Slave ID / Unit ID
Each slave device has a unique address (1-247). The master uses this ID to target a specific device. ID 0 is reserved for broadcast messages.
Function Code
A numeric code (1-127) that tells the slave what operation to perform - read coils, write registers, etc.
Data Payload
Contains the register addresses, quantities, and values depending on the function code being used.
Error Checking
CRC (RTU) or LRC (ASCII) checksum for serial. TCP uses the built-in TCP/IP error detection.
Request/Response Example
This example reads 10 holding registers starting from address 0 on slave ID 1
What is the difference between Modbus TCP and RTU?
Modbus comes in two primary variants. Both carry the same type of data, but the transport layer and frame format differ.
| Aspect | Modbus RTU | Modbus TCP/IP |
|---|---|---|
| Physical Layer | RS-485 / RS-232 serial | Ethernet (Cat5/Cat6) |
| Network Topology | Daisy chain (bus) | Star (switch-based) |
| Speed | Up to 115,200 baud | 10/100/1000 Mbps |
| Max Devices | 247 per bus | Virtually unlimited |
| Cable Distance | Up to 1,200m (RS-485) | 100m per segment |
| Error Detection | CRC-16 checksum | TCP/IP built-in |
| Masters | Single master only | Multiple clients |
| Default Port | COM port (serial) | TCP port 502 |
| Best For | Simple, short-distance, cost-effective setups | Complex networks, long distance, high speed |
Modbus RTU Frame
Modbus TCP Frame
TCP adds a 7-byte MBAP header and removes the CRC (TCP/IP handles error checking)
What are Modbus function codes?
Function codes tell the slave device what action to perform. Here are the most commonly used function codes, all supported by ModbusBB.
Read Functions
Read the ON/OFF status of discrete outputs (coils). Returns a bit array.
Read the ON/OFF status of discrete inputs. Similar to FC 01 but for read-only inputs.
Read the contents of holding registers (read/write 16-bit values). The most commonly used function.
Read the contents of input registers (read-only 16-bit values). Used for sensor data.
Write Functions
Set a single coil to ON (0xFF00) or OFF (0x0000).
Write a single 16-bit value to a holding register.
Set multiple coils to ON/OFF in a single request. More efficient than multiple FC 05 calls.
Write to multiple consecutive holding registers in one request. Essential for 32-bit values.
Exception Responses
When a slave device cannot process a request, it returns an exception response with an error code:
The function code is not supported by the slave device.
The requested register address does not exist on the device.
The value in the request is not acceptable (e.g., out of range).
An internal error occurred in the slave while processing the request.
What are Modbus registers and data types?
Modbus organizes data into four types of memory areas. Understanding these is essential for working with any Modbus device.
Address Range: 00001 - 09999
Type: Single bit (ON/OFF)
Access: Read/Write
Function Codes: FC 01, 05, 15
Example: Relay outputs, motor start/stop, valve open/close
Address Range: 10001 - 19999
Type: Single bit (ON/OFF)
Access: Read Only
Function Code: FC 02
Example: Limit switches, push buttons, sensor status
Address Range: 30001 - 39999
Type: 16-bit word (0 - 65535)
Access: Read Only
Function Code: FC 04
Example: Temperature sensors, analog inputs, measured values
Address Range: 40001 - 49999
Type: 16-bit word (0 - 65535)
Access: Read/Write
Function Codes: FC 03, 06, 16
Example: Setpoints, configuration, control parameters
Common Data Formats
While Modbus registers are 16-bit, real-world values often require different data formats. ModbusBB supports all of these:
16-bit Integer
Single register. Unsigned (0 to 65,535) or signed (-32,768 to 32,767). Most common format.
32-bit Integer
Two consecutive registers combined. Unsigned (0 to ~4.29 billion) or signed. Byte order matters.
Float32 (IEEE 754)
Two registers forming a 32-bit floating point value. Used for temperatures, pressures, flow rates.
64-bit & String
Float64, Int64 and UInt64 use four registers (common for energy counters). Strings pack two ASCII characters per register (serial numbers, model names).
Byte Order
For 32-bit and 64-bit values, the byte order (ABCD, DCBA, BADC, CDAB) varies by manufacturer. ModbusBB supports all four.
Where is Modbus used?
Modbus is used across many industries. Here are some of the most common scenarios where ModbusBB helps engineers and technicians.
Energy & Power
Read power meters, solar inverters, battery management systems, and energy monitoring devices. Track voltage, current, power factor, and kWh consumption.
Manufacturing & PLC
Communicate with PLCs, VFDs (variable frequency drives), and motor controllers. Read status, write setpoints, and control production lines.
HVAC & Building Automation
Monitor and control HVAC systems, chillers, boilers, and environmental sensors. Read temperatures, humidity, and control dampers.
Water & Wastewater
Monitor flow meters, level sensors, pump controllers, and treatment systems. Track flow rates, tank levels, and chemical dosing.
Device Testing & QA
Test new Modbus devices during development. Verify register maps, validate responses, and debug communication issues.
Data Acquisition & SCADA
Collect data from field devices for SCADA systems, historians, and monitoring dashboards. Log values over time for trend analysis.
Video Tutorials
These curated videos will help you understand Modbus visually. Great for beginners and as a refresher for experienced users.
How Does Modbus Communication Protocol Work?
A comprehensive introduction to the Modbus protocol, covering the basics of how devices communicate in industrial automation.
Getting Started with Modbus: Basics and Setup
Learn how to get started with Modbus communication, including setup procedures and configuration basics.
Want to Practice?
Download ModbusBB and use it alongside these tutorials to practice reading and writing to Modbus devices. The 30-day free trial gives you full access to all features.
Download Free TrialModbus Glossary
Key terms you'll encounter when working with Modbus devices and ModbusBB.
- Master / Client
- The device that initiates communication by sending requests. ModbusBB acts as a Modbus master/client.
- Slave / Server
- The device that responds to requests from the master. PLCs, sensors, and meters typically act as slaves. Each has a unique Slave ID (1-247).
- Coil
- A single-bit data point representing an ON/OFF state. Originally named after relay coils in early PLCs. Can be read and written.
- Register
- A 16-bit (2 byte) data storage location in a Modbus device. Holds values from 0 to 65,535 (unsigned) or -32,768 to 32,767 (signed).
- Holding Register
- A read/write register used for configuration values, setpoints, and control parameters. Accessed with FC 03 (read) and FC 06/16 (write).
- Input Register
- A read-only register used for measured values from sensors. Accessed with FC 04.
- Function Code (FC)
- A numeric code in a Modbus request that specifies what operation to perform (e.g., FC 03 = Read Holding Registers).
- CRC (Cyclic Redundancy Check)
- A 2-byte error-checking value appended to Modbus RTU frames to detect data corruption during transmission.
- MBAP Header
- Modbus Application Protocol header used in Modbus TCP. A 7-byte header that replaces the CRC used in RTU.
- Baud Rate
- The speed of serial communication measured in bits per second. Common values: 9600, 19200, 38400, 115200.
- RS-485
- A serial communication standard used by Modbus RTU. Supports multi-drop connections (multiple devices on one bus) up to 1,200 meters.
- Polling
- Repeatedly sending read requests at regular intervals to monitor changing values. ModbusBB supports poll intervals from 100 ms to 1 hour, with several polls running at once on one or more connections.
- Byte Order / Endianness
- The order in which bytes are arranged for multi-register values (32-bit). Common orders: ABCD (Big Endian), DCBA (Little Endian), BADC, CDAB.
- IEEE 754 (Float32)
- A standard for representing floating-point numbers in 32 bits (2 Modbus registers). Used for temperatures, pressures, and other analog values.
Modbus FAQ
Is Modbus still used today?
Yes. Modbus remains one of the most widely supported industrial protocols because it is simple, open and royalty-free. Power meters, drives, inverters, PLCs, HVAC controllers and gateways commonly expose Modbus RTU or Modbus TCP interfaces.
What is the difference between a Modbus master and a slave?
The master (client) starts every transaction by sending a request; the slave (server) only replies. On an RTU serial bus there is a single master, while on Modbus TCP several clients can connect to the same server.
What is a Modbus slave ID?
The slave ID (called Unit ID on Modbus TCP) is the address from 1 to 247 that selects which device answers a request. ID 0 is reserved for broadcast writes, which slaves execute without replying.
